BWsensing IMU400C High-Precision Inertial Measurement Unit

Vendor: BWsensing ( )

Product: IMU400C

BWsensing IMU400C High-Precision Inertial Measurement Unit

BWsensing (Wuxi) IMU400C is a high-precision 6-axis inertial measurement unit: gyro ±400 °/s with 0.01 °/s resolution, bias stability <0.5 °/h (100 s, 1σ) and angular random walk <0.1 °/√h; accelerometer ±3.6 g with 0.01 mg resolution and 0.001 mg bias stability. 500 Hz output over RS232/RS485/TTL, measuring 60×59×29 mm with −40 to +85 °C operation. Vendor-listed applications include unmanned boats/underwater robots, AGVs, robots and drones.

Axes	6 (3-axis accel + 3-axis gyro)
Gyro Arw	<0.1 °/√h
Dimensions	60 × 59 × 29 mm
Interfaces	RS232 / RS485 / TTL
Output Rate	500 Hz
Operating Temp	−40 to +85 °C
Gyro Full Range	±400 °/s
Gyro Resolution	0.01 °/s
Accel Full Range	±3.6 g
Accel Resolution	0.01 mg
Gyro Bias Stability	<0.5 °/h (100 s, 1σ)
Accel Bias Stability	0.001 mg

IMU High Precision BWsensing Beijing Weisensor Unmanned Boat AGV Robots

http://www.bwsensing.com.cn/details_IMU400C-363.html
