HiPNUC HI13 USB Type-C Attitude Sensor

Vendor: HiPNUC ( )

Product: HI13 USB Type-C

HiPNUC (Beijing) HI13 is a stand-alone aluminum-enclosure attitude sensor of 26×24×12 mm with plug-and-play USB Type-C and a fully symmetric design for easy integration. Seven variants M0/M3/R2/R3/S2/S3/S4: M/R series offer ±2000 °/s gyro and ±24 g accelerometer, while S series reach ±4000 °/s and ±32 g, with bias instability up to 1.6 °/h; three variants include a ±2000 μT wide-range magnetometer. USB output up to 1000 Hz, 4.5~5.5 V supply, 215~300 mW, −40 to +85 °C — ideal for robots needing ready-to-read attitude data.

Variants	M0 / M3 / R2 / R3 / S2 / S3 / S4
Interface	USB Type-C
Dimensions	26 × 24 × 12 mm (aluminum)
Output Rate	USB 1000 Hz
Operating Temp	−40 to +85 °C
Supply Voltage	4.5~5.5 V
Gyro Full Range	±2000 °/s (M/R), ±4000 °/s (S)
Accel Full Range	±24 g (M/R), ±32 g (S)
Power Consumption	215~300 mW
Magnetometer Range	±2000 μT (3 variants)
Gyro Bias Instability	up to 1.6 °/h (best variant)

IMU Attitude sensors MEMS HiPNUC USB Type-C Aluminum Alloy Enclosure Geomagnetic

https://www.hipnuc.com/hi13.html
