#Open-source hardware (14)

How to Build a Humanoid Robot: A Seven-Layer Constraint Chain from Joint Modules to Sim-to-Real

A humanoid robot is not an assembly of seven modules but a stack of physics equations that set each other's boundary conditions. This article computes the whole-machine stack layer by layer: joint motor modules (declared torque versus real quasi-static CoP demand — BHL's hip has only 0.9x margin) -> IMU (lever-arm pseudo-acceleration is 21,752x the sensor noise floor, so mounting position matters four orders of magnitude more than the datasheet) -> materials and structure (three BOM revisions of AgiBot's X1 as a load-path history: every part entering the closed-chain drivetrain upgraded to 7075-T6 / TC4 / 17-4PH) -> sensors (fix the observation space before the shopping list) -> battery and BMS ('all joints at peak simultaneously' is physically impossible: G1's 46,062 W against a 421 Wh pack is 109 C) -> software control and the CAN-level low-side boards (22 nodes at 500 Hz on one bus is 130.9% load, so it must be split into four) -> simulation training and sim-to-real (9 of 12 real failure modes are hardware calibration, not simulation fidelity). Every figure comes from programmatic parsing of the five machines' public model files plus official vendor specifications, and is recomputable.

BLOG

HumanoidJoint modulesIMUBMSSim-to-Real

reubenstr/ElectroPup

ElectroPup: a 12-DoF 3D-Printed Open-Source Quadruped

ElectroPup is a 4.5 kg, 12-DoF DIY quadruped: twelve MG4010E-i10v3 CAN BLDC actuators split into four per-leg CAN segments, a Raspberry Pi 5 for compute, and a single ~7,700-line pure-Python service with no ROS in the stack. The repository publishes OnShape CAD, two KiCad v8 boards, a bill of materials, measured weights and power draw (21.6 W suspended, 33.8 W standing), plus MuJoCo simulation, a React Native/Expo browser UI, four Bezier-foot gaits, and a full build guide. The author also documents known gaps: no license file, no contact sensing, and a simulation model without approximate masses or inertias.

Quadruped robotsOpen SourceBLDC Motor

Python3542
